Technical Standard Compatible with WCDMA, FDD-LTE,TDD-LTE Default 802.11b/g/n
Frequency LTE:B1/3/5/7/8/20/38/40/41 WCDMA:B1/5/8
WIFI 2.4G, 802.11 b/g/n
Maximum Data Throughput "LTE CAT 4
FDD-LTE(DL/UL) 150Mbps/50Mbps HSPA+ (DL/UL) 21/5.76Mbps"
Receive Diversity Support Receive Diversity
MIMO Support DL 2x2 MIMO
BB Chipset ASR 1803
WiFi Chipset Wifi4 ASR5803 or Wifi6 AIC8800
WiFi Users 8
power consumption/Power Voltage <10W / DC12V-800mA or TYPE-C 5V-1000mA
Battrey INCLUDE 5000Mah
USIM/SIM "4FF Nano SIM card
support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card;internal"
LED SYSTEM/WiFi Indication LED, LTE/Internet Status Interface Status LED,ETH/Signal Strength LED
Antenna internal WIFI antenna;2 internal LTE antenna; 2 external antenna for optional
Buttons Reset/WPS
Ethernet 100M WAN*1 ,LAN*3, 10BaseT/100Base/ automatic adaptive port
Reset Pinhole
ESD Contact±8KV?Air±10KV
SW Update TR069 & FOTA(customized) & Local
WIFI Mode AP/STATION mode
WIFI Security OPEN & WPA-PSK& WPA2-PSK
SMS YES
IPv4 Support IPv4
IPv6 Support IPv6
Data Statistics Support
SIM Lock Support
HTTP Support
DMZ Support
Operating Temperature Normal:-10°C to +65°C;
Storage Temperature -20° C to +85° C
Humidity 5%~ 95%
